DC Motors |
|
|
|
| |
|
 Data Group: 178
SKU: 1112033
Weight (Kg): 0.2000
Decsription: FC-260SA-2670
HS Code: 8501.31.6000
Applications: Hair Dryer, locks, Auto mirrors
 |
|
|
|
|
| |
Untitled Document
| MFG Model |
VOLTAGE |
NO LOAD |
AT MAXIMUM EFFICIENCY |
STALL |
OPERATING |
NOMINAL |
SPEED |
CURRENT |
SPEED |
CURRENT |
TORQUE |
OUTPUT |
TORQUE |
CURRENT |
VDC |
VDC |
RPM |
A |
RPM |
A |
mN¡¤m |
g¡¤cm |
W |
mN¡¤m |
g¡¤cm |
A |
| FC-260SA-2670 |
3-6 |
4.5 |
14000 |
0.27 |
11660 |
1.34 |
2.94 |
30 |
3.59 |
17.6 |
179 |
6.7 |
| FC-260SA-10300 |
6.0 - 26.5 |
26.5 |
19000 |
0.08 |
15470 |
0.35 |
3.19 |
32.5 |
5.16 |
17.2 |
175 |
1.54 |
| FC-260SA-12250 |
6-28 |
24 |
20600 |
0.08 |
17530 |
0.46 |
3.51 |
35.7 |
6.43 |
23.5 |
240 |
2.6 |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
|
|
| |
