Stepper Motors


Data Group: 520
SKU: 1128002
Weight (Kg): 0.5000
Decsription: 110BYG450
HS Code: 8501.10.4040
Applications: Stage lights, securities, advertisement board



KYSAN SKU
MFG Model
No. of Phase
Step Angel
Voltage (V)
Current (A)
Resistance (O)
Inductance (mH)
Holding Torque N.m
Detent Torque (g.cm)
Rotor Inetia (Kg.cm2)
Weight (Kg)
1128002
110BYG450
4
0.9/1.8
80~200
6
0.22
2.1
7.1
0.6
7.5
7.5
1128004
110BYG007
5
0.36/0.72
130
5
0.3
1.9
6.8
7.5
7.5
1128005
110BYG008
5
0.36/0.72
130
5
0.37
3.4
10.3
11.5
11.5
1128006
110BYG550A
5
0.36/0.72
130
3
0.5
5.3
6.8
7.5
7.5
1128007
110BYG550B
5
0.36/0.72
130
3
0.62
9.5
10.3
11.5
11.5


Step Angle---------------------------------------1.8 ° ±5%
Insulation Resistant----------------500V  DC  100MΩ  Min
Insulation Strength---------------50Hz  1Minute  500V Min
Ambient Temperature ---------------- -20 ~ +50 Degree C
Temperature Rise-------------------80 Degree C Maximum
Radial Play------------------------------0.02 mm Maximum
End Play----------------------------------------0.1-0.3 mm
