Stepper Motors


Data Group: 427
SKU: 1040001
Weight (Kg): 1.0000
Decsription: 17HGS-B1/20
HS Code: 8501.10.4040
Applications: Office automation, banking equipment, auto control unit, telecommunication, home appliances, machine




Features:
1) Product name: special shaft hybrid stepping motor
2) Frame sizes :42*42
3) Step angle: 1.8 or 0.9
4) Speed :1:10,1:30,1:50
5) Shaft style: single or double
7) Lead wires: 4 / 6
8) No. of phase: 2
