DC Motors


Data Group: 1522
SKU: 1112329
Weight (Kg): 0.1000
Decsription: FF-K10WA-3V28200RPM
HS Code: 8483.40.9000
Applications: Camera, toys, and instrument.


  Untitled Document
MFG VOLTAGE NO LOAD AT MAXIMUM EFFICIENCY STALL
Model OPERATING NOMINAL SPEED CURRENT SPEED CURRENT TORQUE OUTPUT TORQUE CURRENT
Number RANGE VDC RPM A RPM A mN·m g·cm W mN·m g·cm A
FF-K10WA-3V11000RPM 3.0-6.0 3 11800 0.04 5800 0.1 0.15 1.5 0.1 0.28 2.8 0.16
FF-K10WA-1.5V9100RPM 1.5-3.0 1.5 9100 0.028 6750 0.08 0.07 0.66 0.046 76 0.25 0.23
FF-K10WA-3V28200RPM 1.5-3.5 3 28200 0.05 20300 0.13 0.07 0.7 0.146 0.25 2.5 0.35
FF-K10WA-3V20500RPM 1.5-3.5 3 20500 0.057 13800 0.12 0.06 0.63 0.089 0.19 1.9 0.25









  ©2003 KYSAN ELECTRONICS All Rights Reserved! www.kysanelectronics.com
