DC Motors


Data Group: 3814
SKU: 1112740
Weight (Kg): 0.0100
Decsription: FF-M10VA-08210
HS Code: 8483.40.9000
Applications: Model air plane



Mfg Votage No Load At Maximum Efficiency Stall
Model Operting Nominal Speed Current Speed Current Torque Output Torque Current
Number Range V r/min A r/min A g.cm W g.cm A
FF-M10NA-07183 1.5-4.5 V 3.6 21500 0.045 16500 0.15 1.4 0.24 5.9 0.474

  Life time: 200 hours on a continuously running base or up to 500-700 hours at intermitentt mode.

Metal brushes
